Highlights
- Rear wheels with drum brakes, removable by quick release.
- Seat and back angle infinitely adjustable to an angle of 45 degrees by means of gas spring
- The Tourer is very agile due to its low weight and good balance
- The TOURER is available with 12″ / 16″ / 20″ / 22″ / 24″ rear wheels.
- The seat height is adjustable by 8 cm.
- The backrest is infinitely adjustable in depth by 7 cm.
- Also available with Trike for better handling on unpaved paths
- To be equipped with diverse types of electric trolling support
- Can be used as a tractor unit or as a self-propelled unit
- Available with one-handed operation
- Crash-tested and certified according to ISO 7179-19
- Customization is possible
Specifications and dimensions
- Seat width 26 – 44 cm
- Seat depth: 33 – 40 cm
- Height: 45 cm
- User weight: 120 kg
- Tilting seat -5 to 45 degrees
- Corner adjustment 90-120 degrees
- Crash test safe: yes
Options
- Available in 4 sizes
- Diverse types of armrests
- Multiple types of footplates
- Swiveling leg rests
- Under-seat luggage compartment
Downloads
Chassis Tourer
The TOURER belongs to the new generation of frames for seating shells and orthopedic seating systems. Due to its modern and well-thought-out design, the extremely stable construction is very light. This base makes many things easier in everyday life. For example, the TOURER enables children to actively participate in life again with their parents or caregivers.
Chassis Order Form Tourer
This Tourer is prepared for use with the Mosa seat unit.
Would you like to assemble or add a suitable Mosa directly? Then click here.
